STR720 - EXTENDED FUNCTION TIMER (EFT)
331/401
21.4.1
Register Map
A summary of the EFT registers is given in the following table.
Refer to Table 20 on page 49 for the base address.
Table 69. Extended Function Timer Register Map
Addr.
Offset
Register
Name
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
0
ICAR
Input Capture A
4
ICBR
Input Capture B
8
OCAR
Output Compare A
C
OCBR
Output Compare B
10
CNTR
Counter Value
14
CR1
EN
PWMI
reserved
FOLVB FOLVA OLVLB OLVLA
OCBE
OCAE
OPM
PWM
IEDGB IEDGA EXEDG ECKEN
18
CR2
ICAIE
OCAIE
TOE
ICBIE
OCBIE
reserved
CC7
CC6
CC5
CC4
CC3
CC2
CC1
CC0
1C
SR
ICFA
OCFA
TOF
ICFB
OCFB
reserved
1
