ST7LITE3

160/167

15.2 DEVICE ORDERING INFORMATION AND TRANSFER OF CUSTOMER CODE

Customer code is made up of the FASTROM con-

tents and the list of the selected options (if any).

The FASTROM contents are to be sent on dis-

kette, or by electronic means, with the S19 hexa-

decimal file generated by the development tool. All

unused bytes must be set to FFh. The selected op-

tions are communicated to STMicroelectronics us-

ing the correctly completed OPTION LIST append-

ed on page 161.

Refer to application note AN1635 for information

on the counter listing returned by ST after code

has been transferred.

The STMicroelectronics Sales Organization will be

pleased to provide detailed information on con-

tractual points.

Table 24. Supported part numbers

Part Number

Program

Memory

(Bytes)

Data

EEPROM

(Bytes)

RAM

(Bytes)

INTERNAL

Temp.

Range

Package

ST7FLITE30F2B6

8K FLASH

384

-40°C +85°C

DIP20

ST7FLITE30F2M6

SO20

ST7FLITE35F2B6

yes

DIP20

ST7FLITE35F2M6

yes

SO20

ST7FLITE39F2B6

256

yes

DIP20

ST7FLITE39F2M6

256

yes

SO20

Contact ST sales office for product availability
