DS12288 Rev 5

231/236

STM32G474xB STM32G474xC STM32G474xE

Package information

232

6.10.2

Selecting the product temperature range

When ordering the microcontroller, the temperature range is specified in the ordering

information scheme shown in Section 7: Ordering information.

Each temperature range suffix corresponds to a specific guaranteed ambient temperature at

maximum dissipation and, to a specific maximum junction temperature.

As applications do not commonly use the STM32G474xE at maximum dissipation, it is

useful to calculate the exact power consumption and junction temperature to determine

which temperature range is best suited to the application.

The following examples show how to calculate the temperature range needed for a given

application.

Example 1: High-performance application

Assuming the following application conditions:

Maximum ambient temperature TAmax = 82 °C (measured according to JESD51-2),

IDDmax = 50 mA, VDD = 3.5 V, maximum 20 I/Os used at the same time in output at low

level with IOL = 8 mA, VOL= 0.4 V and maximum 8 I/Os used at the same time in output

at low level with IOL = 20 mA, VOL= 1.3 V

PINTmax = 50 mA × 3.5 V= 175 mW

PIOmax = 20 × 8 mA × 0.4 V + 8 × 20 mA × 1.3 V = 272 mW

This gives: PINTmax = 175 mW and PIOmax = 272 mW:

PDmax = 175 + 272 = 447 mW

Using the values obtained in TJmax is calculated as follows:

–

For LQFP100, 42 °C/W

TJmax = 82 °C + (42 °C/W × 447 mW) = 82 °C + 18.774 °C = 100.774 °C

This is within the range of the suffix 6 version parts (–40 < TJ < 105 °C) see Section 7:

Ordering information.

In this case, parts must be ordered at least with the temperature range suffix 6 (see

Section 7: Ordering information).

Note:

With this given PDmax we can find the TAmax allowed for a given device temperature range

(order code suffix 6 or 7).

Suffix 6: TAmax = TJmax - (42°C/W × 447 mW) = 105-18.774 = 86.226 °C

Suffix 3: TAmax = TJmax - (42°C/W × 447 mW) = 130-18.774 = 111.226 °C

Example 2: High-temperature application

Using the same rules, it is possible to address applications that run at high ambient

temperatures with a low dissipation, as long as junction temperature TJ remains within the

specified range.
