7.10 Timing and Switching Characteristics

Note

The Timing Requirements and Switching Characteristics values may change following the silicon

characterization result.

Note

The default SLEWRATE settings in each pad configuration register must be used to ensure timings,

unless specific instructions are given otherwise.

7.10.1 Timing Parameters and Information

The timing parameter symbols used in Timing and Switching Characteristics sections are created in accordance

with JEDEC Standard 100. To shorten the symbols, some pin names and other related terminologies have been

abbreviated in Table 7-3:

Table 7-3. Timing Parameters Subscripts

SYMBOL

PARAMETER

Cycle time (period)

Delay time

dis

Disable time

Enable time

Hold time

Setup time

START

Start bit

Transition time

Valid time

Pulse duration (width)

Unknown, changing, or don't care level

Fall time

High

Low

Rise time

Valid

Invalid

Active Edge

First Edge

Last Edge

High impedance

www.ti.com

AM6442, AM6441, AM6421, AM6412, AM6411

SPRSP56D – JANUARY 2021 – REVISED JULY 2022

Submit Document Feedback

111

Product Folder Links: AM6442 AM6441 AM6421 AM6412 AM6411
