Note

Internal pull resistors are weak and may not source enough current to maintain a valid logic level

for some operating conditions. This can be the case when connected to components with leakage

to the opposite logic level, or when external noise sources couple to signal traces attached to balls

which are only pulled to a valid logic level by the internal resistor. Therefore, external pull resistors are

recommended to hold a valid logic level on balls with external connections.

If balls are allowed to float between valid logic levels, the input buffer can enter a high-current state

which can damage the IO cell.

AM2434, AM2432, AM2431

SPRSP65D – APRIL 2021 – REVISED AUGUST 2022

www.ti.com

114

Submit Document Feedback

Product Folder Links: AM2434 AM2432 AM2431
