7.10 Timing and Switching Characteristics
This section describes the device Timing Parameters and Switching Characteristics.
7.10.1 Timing Parameters and Information
The timing parameter symbols used in Timing and Switching Characteristics sections are created in accordance
with JEDEC Standard 100. To shorten the symbols, some pin names and other related terminologies have been
abbreviated in Table 7-3:
Table 7-3. Timing Parameters Subscripts
SYMBOL
PARAMETER
c
Cycle time (period)
d
Delay time
dis
Disable time
en
Enable time
h
Hold time
su
Setup time
START
Start bit
t
Transition time
v
Valid time
w
Pulse duration (width)
X
Unknown, changing, or don't care level
F
Fall time
H
High
L
Low
R
Rise time
V
Valid
IV
Invalid
AE
Active Edge
FE
First Edge
LE
Last Edge
Z
High impedance
AM2434, AM2432, AM2431
SPRSP65D – APRIL 2021 – REVISED AUGUST 2022
www.ti.com
130
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated
Product Folder Links: AM2434 AM2432 AM2431
