123 / 280 page  7.7.2 Fail-Safe Reset (FS RESET) Electrical Characteristics over recommended operating conditions (unless otherwise noted) PARAMETER TEST CONDITIONS MIN TYP MAX UNIT VIL Input Low Voltage 0.3 × VDDS_OSC V VILSS Input Low Voltage Steady State 0.3 × VDDS_OSC V VIH Input High Voltage 0.7 × VDDS_OSC V VIHSS Input High Voltage Steady State 0.7 × VDDS_OSC V VHYS Input Hysteresis Voltage 200 mV IIN Input Leakage Current. VI = 1.8 V or VI = 0 V ±10 µA SRI (2) Input Slew Rate 18f(1) or 1.8E+6 V/s (1) f = toggle frequency of the input signal in Hz. (2) This MIN parameter only applies to input signal functions which are not defined in their respective Timing and Switching Characteristics sections. Select the MIN parameter which results in the largest value. 7.7.3 High-Frequency Oscillator (HFOSC) Electrical Characteristics over recommended operating conditions (unless otherwise noted) PARAMETER TEST CONDITIONS MIN TYP MAX UNIT VIL Input Low Voltage 0.35 × VDDS_OSC V VIH Input High Voltage 0.65 × VDDS_OSC V VHYS Input Hysteresis Voltage 49 mV IIN Input Leakage Current. VI = 1.8 V or VI = 0.0 V ±10 µA 7.7.4 eMMCPHY Electrical Characteristics over recommended operating conditions (unless otherwise noted) PARAMETER TEST CONDITIONS MIN TYP MAX UNIT VIL Input Low Voltage 0.35 × VDDS_MMC0 V VILSS Input Low Voltage Steady State 0.20 V VIH Input High Voltage 0.65 × VDDS_MMC0 V VIHSS Input High Voltage Steady State 1.4 V IIN Input Leakage Current. VI = 1.8 V or 0 V ±10 µA RPU Pull-up Resistor 15 20 25 kΩ RPD Pull-down Resistor 15 20 25 kΩ VOL Output Low Voltage IOL = 2 mA 0.30 V VOH Output High Voltage IOH = -2 mA VDDS_MMC0 - 0.30 V SRI Input Slew Rate 5E+8 V/s www.ti.com AM2434, AM2432, AM2431 SPRSP65D – APRIL 2021 – REVISED AUGUST 2022 Copyright © 2022 Texas Instruments Incorporated Submit Document Feedback 123 Product Folder Links: AM2434 AM2432 AM2431 |
|
