www.national.com
282
Revision 0.8
USB Register Descriptions (Continued)
5.5.4.6
Host Controller Interrupt Disable (USBC_HcInterruptDisable)
Writing a 1 to a bit in this register clears the corresponding bit, while writing a 0 leaves the bit unchanged.
USB Memory Offset
14h
Type
HCD:
HC:
R/W
RO
Reset Value
00000000h
USBC_HcInterruptDisable Register Map
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10
98
7654321
0
RSVD
USBC_HcInterruptDisable Bit Descriptions
Bit
Name
HCD
HC
Description
31
MasterInterrupt
Enable
R/W
RO
Master Interrupt Disable. Global interrupt disable. A write of 1
disables all interrupts.
30
Ownership
ChangeEnable
R/W
RO
Ownership Change Disable.
0: Ignore.
1: Disable interrupt generation due to Ownership Change.
29:7
RSVD
R/W
RO
Reserved. Read/write 0s.
6
RootHubStatus
ChangeEnable
R/W
RO
Root Hub Status Change Disable.
0: Ignore.
1: Disable interrupt generation due to Root Hub Status Change.
5
FrameNumber
OverflowEnable
R/W
RO
Frame Number Overflow Disable.
0: Ignore.
1: Disable interrupt generation due to Frame Number Overflow.
4
Unrecoverable
ErrorEnable
R/W
RO
Unrecoverable Error Disable. This event is not implemented. All
writes to this bit will be ignored.
3
Resume
DetectedEnable
R/W
RO
Resume Detected Disable.
0: Ignore.
1: Disable interrupt generation due to Resume Detected.
2StartOfFrame
Enable
R/W
RO
Start Of Frame Disable.
0: Ignore.
1: Disable interrupt generation due to Start of Frame.
1
WritebackDone
HeadEnable
R/W
RO
Writeback Done Head Disable.
0: Ignore.
1: Disable interrupt generation due to Writeback Done Head.
0
Scheduling
OverrunEnable
R/W
RO
Scheduling Overrun Disable.
0: Ignore.
1: Disable interrupt generation due to Scheduling Overrun.
