Tolerances if not otherwise shown

According to DIN ISO 2768-1

Linear measures:

up to 30mm class M, otherwise class C

According to DIN ISO 2768-2

Form and position: class L

SCALE

1:1 WEIGHT

SHEET

SIZE

DRAWING TITLE

PART NUMBER

Ledil Oy

Salorankatu 10

FIN 24240 SALO

Finland

THIRD ANGLE PROJECTION:

This drawing is the property

of LEDiL Oy. It may not be

reproduced, copied or

communicated without a written

agreement with LEDiL Oy.

1/1

clear

INDEX

PART NO

DESCRIPTION MATERIAL COLOUR

C14018

2X6-SEAL25

Silicone

C14887

HB-IP-2X6-RS

PMMA

CS14895_HB-IP-2X6_Mechanical model

CS14895

58,8 g

54.2

50.8

25.4

146.5

(

)

PCB typically 146,6mm

1.7

Wiring:

PCB is fully sealed between

the lens with silicone seal

and the heatsink. Wiring

needs to be done through the

PCB and heatsink to

maintain high IP rating.

LED position

173

Fasten middle screws first. Recommended torque

with pan head screw: 0.57Nm

(for 1.6mm thick PCB, no thermal pad)

3.2

Detail B

Scale 2:1

Detail A

Scale 2:1

3.4

M3 screw size

Section view D-D

Scale 2:1

1.6 (1.6mm pcb)

9.64

Section view C-C

Scale 1:1

Ribs

Silicone seal is tested to work in

LEDiL test assemblies. Customer is

recommended to test the sealing in

the end product due many variables,

such as heat sink surface and

possible chemical traces
