CP20.241-R1, CP20.241-R2, CP20.241-R3,

CP20.242-R2, CP20.242-R2-C1

CP-Series

Jan. 2018 / Rev. 0.2 DS-CP20.241-R2-EN - All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 20A output

load, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.

www.pulspower.com Phone +49 89 9278 0

Germany

2/33

P R E L I M I N A R Y

Page

Page

1.

Intended Use .......................................................4

2.

Installation Requirements...................................4

3.

AC-Input...............................................................6

4.

DC-Input...............................................................7

5.

Input Inrush Current ...........................................8

6.

Output .................................................................9

7.

Hold-up Time.....................................................10

8.

DC-OK Relay Contact ........................................11

9.

Efficiency and Power Losses..............................12

10. Lifetime Expectancy ..........................................13

11. MTBF ..................................................................13

12. Functional Diagram...........................................14

13. Terminals and Wiring........................................15

14. Replacing Units while the System is Running ..16

15. Front Side and User Elements...........................17

16. EMC....................................................................18

17. Environment ......................................................20

18. Safety and Protection Features ........................21

19. Dielectric Strength............................................ 22

20. Approvals .......................................................... 23

21. Other Fulfilled Standards ................................. 23

22. Physical Dimensions and Weight ..................... 24

23. Accessories ........................................................ 26

23.1. ZM5.WALL – Wall/Panel Mount Bracket .26

24. Application Notes............................................. 27

24.1. Peak Current Capability ...........................27

24.2. Adjusting the Output Voltage .................28

24.3. Charging of Batteries ...............................29

24.4. Output Circuit Breakers............................29

24.5. Series Operation .......................................30

24.6. Parallel Use to Increase Output Power....30

24.7. Parallel Use for Redundancy ....................31

24.8. Operation on Two Phases ........................32

24.9. Use in a Tightly Sealed Enclosure ............32

24.10. Mounting Orientations ............................33
