SFH203PFA datasheet(2/9 Pages) OSRAM

2 / 9 page

2015-12-23

Version 1.3

SFH 203 PFA

Maximum Ratings (TA = 25 °C)

Characteristics (TA = 25 °C)

Parameter

Symbol

Values

Unit

Operating and storage temperature range

op; Tstg

-40 ... 100

°C

Reverse voltage

(t < 2 min)

Total Power dissipation

tot

150

ESD withstand voltage

(acc. to ANSI/ ESDA/ JEDEC JS-001 - HBM)

VESD

2000

Parameter

Symbol

Values

Unit

Photocurrent

R = 5 V, λ = 870 nm, Ee = 1 mW/cm

(typ (min))

6.2 (≥ 3.6)

µA

Wavelength of max. sensitivity

(typ)

S max

900

Spectral range of sensitivity

(typ)

10%

(typ) 750

... 1100

Radiant sensitive area

(typ)

1.00

Dimensions of radiant sensitive area

(typ)

L x W

1 x 1

mm x

Half angle

(typ)

± 75

Dark current

R = 20 V)

(typ (max)) IR

1 (≤ 5)

Spectral sensitivity of the chip

(λ = 850 nm)

(typ)

λ typ

0.62

A / W

Quantum yield of the chip

(λ = 850 nm)

(typ)

0.90

Electro

/Photon

Open-circuit voltage

e = 0.5 mW/cm

2, λ = 870 nm)

(typ (min))

300 (≥ 250)

Short-circuit current

e = 0.5 mW/cm

2, λ = 870 nm)

(typ)

µA

Rise and fall time

(VR = 20 V, RL = 50 Ω, λ = 850 nm)

(typ)

r, tf

0.005

µs

Forward voltage

(IF = 100 mA, E = 0)

(typ)

1.3

Capacitance

R = 0 V, f = 1 MHz, E = 0)

(typ)

Temperature coefficient of V

(typ)

-2.6

mV / K
