LOCKING DEVICE

This is supplied as an option.

The available spindle length is according to the panel

thickness.

Order reference: DBA10

Note

• For any special requirement on request: spindle flats, etc. Please

supply detailed drawing.

MARKING

Vishay Sfernice trademark, series, style, ohmic value (in

 or k), tolerance (in %), maximum current in A, manufacturing date

SPINDLES

Ø

mm

DISTANCE TO

MOUNTING

PLATE MM

SCREW

DRIVER

SLOT

CODE

10

50

Without

AS

thumb

wheel nut

min. panel cut-out

Ø 32

panel

18

17

PARTICULAR CHARACTERISTICS

NOMINAL

RESISTANCE



MAX. SERVICE

VOLTAGE

V

MAX. CURRENT

THROUGH WIPER

A

1

15.2

15.2

1.5

18.6

12.4

2.2

22.5

10.2

3.3

27.6

8.36

4.7

32.9

7

6.8

31.5

5.82

10

48

4.80

15

58.7

3.92

22

71.1

3.23

33

87.1

2.64

47

104

2.21

68

125

1.84

100

152

1.52

150

186

1.24

220

225

1.02

330

276

0.836

470

329

0.700

680

395

0.582

1K

480

0.480

1.5K

587

0.392

2.2K

711

0.323

3.3K

871

0.264

4.7K

1040

0.221

6.8K

1250

0.184

10K

1500

0.150

15K

1940

0.13

22K

2000

0.091

COMMAND KNOB 60JF (OPTION)

21

Ø 76

Ø 10

16

DIAL CG115 (OPTION)

4 holes Ø 3.5

Ø 12

5

6

7

8

9

10

0

1

2

3

4

115

98

2 holes Ø 6

98

50

115
