DS18004 Rev. 21 - 2

2 of 3

BZT52C2V0 - BZT52C39

www.diodes.com

Type

Number

(Note 5)

Marking

Codes

Zener Voltage Range

(Note 2)

Maximum Zener

Impedance (Note 3)

Maximum

Reverse

Current

(Note 2)

Typical

Temperature

Coefficient

mV/

°C

Test

Current

Nom (V)

Min (V) Max (V)

mA

W

mA

uA

V

Min

Max

mA

BZT52C2V0

WY, WY

2.0

1.91

2.09

5

100

600

1.0

150

1.0

-3.5

0

5

BZT52C2V4

WX, WX

2.4

2.2

2.6

5

100

600

1.0

50

1.0

-3.5

0

5

BZT52C2V7

W1, W1

2.7

2.5

2.9

5

100

600

1.0

20

1.0

-3.5

0

5

BZT52C3V0

W2, W2

3.0

2.8

3.2

5

95

600

1.0

10

1.0

-3.5

0

5

BZT52C3V3

W3, W3

3.3

3.1

3.5

5

95

600

1.0

5.0

1.0

-3.5

0

5

BZT52C3V6

W4, W4

3.6

3.4

3.8

5

90

600

1.0

5.0

1.0

-3.5

0

5

BZT52C3V9

W5, W5

3.9

3.7

4.1

5

90

600

1.0

3.0

1.0

-3.5

0

5

BZT52C4V3

W6, W6

4.3

4.0

4.6

5

90

600

1.0

3.0

1.0

-3.5

0

5

BZT52C4V7

W7, W7

4.7

4.4

5.0

5

80

500

1.0

3.0

2.0

-3.5

0.2

5

BZT52C5V1

W8, W8

5.1

4.8

5.4

5

60

480

1.0

2.0

2.0

-2.7

1.2

5

BZT52C5V6

W9, W9

5.6

5.2

6.0

5

40

400

1.0

1.0

2.0

-2

2.5

5

BZT52C6V2

WA, WA

6.2

5.8

6.6

5

10

150

1.0

3.0

4.0

0.4

3.7

5

BZT52C6V8

WB, WB

6.8

6.4

7.2

5

15

80

1.0

2.0

4.0

1.2

4.5

5

BZT52C7V5

WC, WC

7.5

7.0

7.9

5

15

80

1.0

1.0

5.0

2.5

5.3

5

BZT52C8V2

WD, WD

8.2

7.7

8.7

5

15

80

1.0

0.7

5.0

3.2

6.2

5

BZT52C9V1

WE, WE

9.1

8.5

9.6

5

15

100

1.0

0.5

6.0

3.8

7.0

5

BZT52C10

WF, WF

10

9.4

10.6

5

20

150

1.0

0.2

7.0

4.5

8.0

5

BZT52C11

WG, WG

11

10.4

11.6

5

20

150

1.0

0.1

8.0

5.4

9.0

5

BZT52C12

WH, WH

12

11.4

12.7

5

25

150

1.0

0.1

8.0

6.0

10.0

5

BZT52C13

WI, WI

13

12.4

14.1

5

30

170

1.0

0.1

8.0

7.0

11.0

5

BZT52C15

WJ, WJ

15

13.8

15.6

5

30

200

1.0

0.1

10.5

9.2

13.0

5

BZT52C16

WK, WK

16

15.3

17.1

5

40

200

1.0

0.1

11.2

10.4

14.0

5

BZT52C18

WL, WL

18

16.8

19.1

5

45

225

1.0

0.1

12.6

12.4

16.0

5

BZT52C20

WM, WM

20

18.8

21.2

5

55

225

1.0

0.1

14.0

14.4

18.0

5

BZT52C22

WN, WN

22

20.8

23.3

5

55

250

1.0

0.1

15.4

16.4

20.0

5

BZT52C24

WO, WO

24

22.8

25.6

5

70

250

1.0

0.1

16.8

18.4

22.0

5

BZT52C27

WP, WP

27

25.1

28.9

2

80

300

0.5

0.1

18.9

21.4

25.3

2

BZT52C30

WQ, WQ

30

28.0

32.0

2

80

300

0.5

0.1

21.0

24.4

29.4

2

BZT52C33

WR, WR

33

31.0

35.0

2

80

325

0.5

0.1

23.1

27.4

33.4

2

BZT52C36

WS, WS

36

34.0

38.0

2

90

350

0.5

0.1

25.2

30.4

37.4

2

BZT52C39

WT, WT

39

37.0

41.0

2

130

350

0.5

0.1

27.3

33.4

41.2

2

Notes:

2. Short duration test pulse used to minimize self-heating effect.

3. f = 1kHz.

Device

Packaging

Shipping

(Type Number)-7*

SOD-123

3000/Tape & Reel

* Add “-7” to the appropriate type number in Table 1 above example: 6.2V Zener = BZT52C6V2-7.

Notes:

4. For Packaging Details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.

5. For lead free terminal plating part number, please add "-F" suffix to part number above. Example: BZT52C2V0-7-F.
