PRODUCT FAMILY DATA SHEET

C566T-RFS/AFS

Copyright © 2010 Cree, Inc. All rights reserved. The information in this document is subject to change without notice.

Cree, the Cree logo and XLamp are registered trademarks of Cree, Inc.

PRODUCT DESCRIPTION

The oval LED is specifically designed

for variable-message signs and pas-

senger-information signs.The oval-

shaped radiation pattern and high

luminous intensity ensure that these

devices are excellent for wide-field-

of -view outdoor applications where a

wide viewing angle and readability in

sunlight are essential.

These lamps are tinted and diffused.

The encapsulation resin contains anti-

UV material in order to reduce the ef-

fects of long-term exposure to direct

sunlight.

FEATURES

•

Size (mm): 5

•

Color and Typical Dominant

Wavelength:

Red (628nm)

Amber (591nm)

•

Luminous Intensity (mcd)

C566T-RFS:

(550 - 1520)

C566T-AFS:

(550 - 1520)

•

Viewing angle:

70 X 40 degree

•

Lead - Free

•

RoHS Compliant

Cree, Inc.

4600 Silicon Drive

Durham, NC 27703

USA Tel: +1.919.313.5300

www.cree.com/xlamp

Copyright © 2011 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree and

the Cree logo are registered trademarks of Cree, Inc.

Cree, Inc.

4600 Silicon Drive

Durham, NC 27703

USA Tel: +1.919.313.5300

APPLICATIONS

•

Electronic Signs & Signals

(ESS)

•

Full Color video screen

•

Motorway Signs

•

Variable Message Sign (VMS)

•

Advertising signs

•

Petrol Signs
