SMD Shielded Flat Wire Power Choke

15

ALLIED COMPONENTS INTERNATIONAL

949-356-1780

www.alliedcomponents.com

RoHS

03/29/2017

Features

•Magnetically Shielded Construction

Electrical

Inductance Range: 0.20µH to 10µH

Tolerance: 20% over entire range

Operating Temp: -55ºC ~ +125ºC

Pre-Heat: 160ºC ±10°C

Test Equipment

(L): HP4284A LCR meter

•Ultra High Saturation Current up to 14A

Resistance to Soldering Heat

Solder Heat Resistance: 260ºC ± 5ºC for 10±1 sec.

DCR: Milli-ohm meter

Test Frequency: 100KHz, 0.25V

•Low DC Resistance

•Expanded operating temp range

Temp: 85°C ± 2°C

•Suitable for pick and place

Physical

Packaging: 2000pcs per 13 inch reel

Marking: EIA Inductance Code

All specifications subject to change without notice.

Allied

Part

Number

Inductance

(µH)

Irms

(A)

Test

Frequency

(KHz, 0.25V)

Tolerance

(±%)

DCR

(mΩ)

Max

14.0

11.0

9.0

8.5

8.2

7.0

5.5

4.5

3.5

3.2

Isat

(A)

Typ

Storage Temp: -55ºC ~ +125ºC

Irms: Current at which The Temperature would

Rise by Approximately 40°C

Isat: Current at which The Inductance will Drop

by Approximately 30%

Under no condition should the part exceed 125°C

PCSFW530

PCSFW530-R20M

PCSFW530-R47M

PCSFW530-R68M

PCSFW530-1R0M

PCSFW530-1R5M

PCSFW530-2R2M

PCSFW530-3R3M

PCSFW530-4R7M

PCSFW530-6R8M

PCSFW530-100M

0.20

0.47

0.68

1.0

1.5

2.2

3.3

4.7

6.8

10

20

100

3.9

8.5

12.0

14.0

25.0

29.0

38.0

60.0

90.0

125.0

14.5

12.0

11.5

11.0

8.5

7.5

6.0

5.0

4.0

3.5

100

A

B

C

D

E

F

G

H

5.2±0.20

2.8±0.2

1.2±0.2

2.5

5.4±0.3

2.2±0.3

1.9

2.2

Dimensions: (mm)
