LE CW S2LN

OSRAM OSTAR - Lighting plus

Lead (Pb) Free Product - RoHS Compliant

Vorläufige Daten / preliminary data

2011-07-25

1

Besondere Merkmale

• Gehäusetyp: Kompakte Lichtquelle in

Multi-Chip SMT Technologie mit Silikonlinse

• Besonderheit des Bauteils: extrem hohe

Helligkeit und Leuchtdichte dank

Oberflächenemission und hoher

Chip-Packungsdichte

• Typischer Lichtstrom: 365 lm bei 350 mA

(3000 K)

• Typische Farbtemperatur: 2700 K; 3000 K;

4000 K; 5000 K

• Typischer Farbwiedergabeindex: 80

• Abstrahlwinkel: 140°

• Lötmethode: Reflow Löten

• ESD-Festigkeit: ESD-sicher bis 2 kV nach

JESD22-A114-D

• Erweiterte Korrosionsfestigkeit:

Details siehe Seite 15

• Feuchtestabilität:

Details siehe Seite 15

Anwendungen

• Ladenbeleuchtung

• Spots und Schreibtischbeleuchtung

• Lampenretrofits

• Anwendungen mit Reflektoroptiken

• Downlights

Features

• Package: compact lightsource in multi chip

SMT technology with silicone lens

• Feature of the device: outstanding brightness

and luminance due to pure surface emission

and high chip packing density

• Typical Luminous Flux: 365 lm at 350 mA

(3000 K)

• Typ. color temperature: 2700 K; 3000 K;

4000 K; 5000 K

• Typ. color rendering index: 80

• Viewing angle: 140°

• Soldering methods: reflow soldering

• ESD-withstand voltage: up to 2 kV acc. to

JESD22-A114-D

• Superior Corrosion Robustness:

details see page 15

• Humidity Robustness:

details see page 15

Applications

• Shop lighting

• Spot- and tasklights

• Retrofit lamps

• Applications using reflector lamps

• Downlights
