EV5416-R-00B 5V POWER MANAGEMENT IC EVALUATION BOARD

NOTICE:

The information in this document is subject to change without notice. Please contact MPS for current specifications.

Users should warrant and guarantee that third party Intellectual Property rights are not infringed upon when integrating MPS

products into any application. MPS will not assume any legal responsibility for any said applications.

EV5416-R-00B Rev.1.1

www.MonolithicPower.com

7

6/7/2017

MPS Proprietary Information. Patent Protected. Unauthorized Photocopy and Duplication Prohibited.

© 2017 MPS. All Rights Reserved.

QUICK START GUIDE

1. Connect the positive and negative terminals of the load to the VOUT and GND pins,

respectively.

2. Preset the power supply output between 3.5V and 5V, and then turn off the power supply.

3. Connect the positive and negative terminals of the power supply output to the VIN and GND

pins, respectively.

4. Turn the power supply on. The PMIC will automatically entry power on sequence.

Notes:

1) VOUT power terminals on EVB are including buck1-4; LDO1 to LDO5.

2) VIN1-4 terminals are shorten-circuit internally. Connect input DC voltage source to either of them is ok.
