ADL5531
Data Sheet
Rev. C | Page 8 of 12
0
5
10
15
20
25
30
35
40
45
37.5
37.9
38.3
38.7
39.1
39.5
39.9
40.3
OIP3 (dBm)
Figure 9. OIP3 Distribution at 190 MHz
0
10
20
30
40
50
60
20.0
20.2
20.4
20.6
20.8
21.0
21.2
21.4
P1dB (dBm)
Figure 10. P1dB Distribution at 190 MHz
0
5
10
15
20
25
30
35
40
45
50
19.7
19.9
20.1
20.3
20.5
20.7
20.9
19.8
20.0
20.2
20.4
20.6
20.8
21.0
GAIN (dB)
Figure 11. Gain Distribution at 190 MHz
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
0
50
100
150
200
250
300
350
400
450
500
FREQUENCY (MHz)
Figure 12. Noise Figure vs. Frequency at 25°C, Multiple Devices Shown
50
60
70
80
90
100
110
120
130
140
150
–40 –30 –20 –10
0
10
20
30
40
50
60
70
80
90
TEMPERATURE (°C)
5V
4.75V
5.25V
Figure 13. Supply Current vs. Supply Voltage and Temperature
115
55
60
65
70
75
80
85
90
95
100
105
110
–6
–4
–2
02468
10
12
14
16
18
20
22
POUT (dBm)
+25°C
–40°C
+85°C
Figure 14. Supply Current vs. POUT and Temperature
