2017-10-26

1

2017-10-26

OSLON Square

Datasheet

Version 1.6(not for new design)

GW CSSRM1.PC

Higher performance. Lower thermal resistance.

Extended range of driving conditions. This is the

second generation OSLON Square.

Verbesserte Leistung. VerringerterWärmewiderstand.

Erweiteter zulässigerBetriebsbereich. Das ist die

zweite Generation der OSLON Square.

Features:

Besondere Merkmale:

•

Package: SMT ceramic package with silicone resin

and silicone lens

•

Gehäusetyp: SMT-Keramikgehäuse mit

Silikonverguss und -linse

•

Viewing angle at 50 % I

V: 120°

•

Abstrahlwinkel bei 50 % I

V: 120°

•

Color: 3000 K - 6500 K (white)

•

Farbe: 3000 K - 6500 K (weiß)

•

CRI: min. 70 ( typ. 72 )

•

CRI: min. 70 ( typ. 72 )

•

Luminous Flux: typ. 301 lm @ 5000 K, 85 °C

•

Lichtstrom: typ. 301 lm @ 5000 K, 85 °C

•

Luminous efficacy: typ. 154 lm/W @ 5000 K,

85 °C

•

Lichtausbeute: typ. 154 lm/W @ 5000 K, 85 °C

•

Corrosion Robustness: Superior Corrosion

Robustness

•

Korrosionsstabilität: Höchste

Korrosionsbeständigkeit

•

Lumen Maintenance: Test results according to

IESNA LM-80 available

•

Lichtstromerhaltung: Testergebnisse nach

IESNA LM-80 verfügbar

Applications

Anwendungen

•

Industrial lighting

•

Industriebeleuchtung

•

Outdoor lighting

•

Außenbeleuchtung

•

Street and tunnel lighting

•

Straßen und Tunnel
