2017-10-26

2

Version 1.2

GW CSSRM2.CM

Ordering Information

Bestellinformation

Type:

Color

Temperature

Luminous Flux

Ordering Code

Typ:

Farbtemperatur

Lichtstrom

Bestellnummer

85 °C

[K]

GW CSSRM2.CM-M1M3-A838-1

2700

180 ... 210

Q65112A0828

GW CSSRM2.CM-M1M3-XX58-1

2700

180 ... 210

Q65112A0827

GW CSSRM2.CM-M2M4-A838-1

2700

190 ... 220

Q65112A0858

GW CSSRM2.CM-M2M4-XX58-1

2700

190 ... 220

Q65112A0853

GW CSSRM2.CM-M3M5-A737-1

3000

200 ... 230

Q65112A0857

GW CSSRM2.CM-M3M5-XX57-1

3000

200 ... 230

Q65112A0844

GW CSSRM2.CM-M4M6-A636-1

3500

210 ... 240

Q65112A0854

GW CSSRM2.CM-M4M6-XX56-1

3500

210 ... 240

Q65112A0966

GW CSSRM2.CM-M5M7-A535-1

4000

220 ... 250

Q65112A0855

GW CSSRM2.CM-M5M7-XX55-1

4000

220 ... 250

Q65112A0845

GW CSSRM2.CM-M4M6-A535-1

4000

210 ... 240

Q65112A0824

GW CSSRM2.CM- M4M6-XX55-1

4000

210 ... 240

Q65112A0823

GW CSSRM2.CM-M6M8-A232-1

5700

230 ... 260

Q65112A0846

GW CSSRM2.CM-M6M8-XX52-1

5700

230 ... 260

Q65112A0848

GW CSSRM2.CM-M6M8-A131-1

6500

230 ... 260

Q65112A0850

GW CSSRM2.CM-M6M8-XX51-1

6500

230 ... 260

Q65112A0851

Note:

The above Type Numbers represent the order groups which include only a few brightness groups (see page 6). Only one group will

be shipped on each packing unit (there will be no mixing of two groups on each packing unit). E. g. GW CSSRM2.CM-M1M3-XX58-1

means that only one group M1, M2, M3 will be shippable for any packing unit.

In a similar manner for colors where color chromaticity coordinate groups are measured and binned, single groups will be shipped on

any one packing unit. GW CSSRM2.CM-M1M3-XX58-1 means that the device will be shipped within the specified limits.

In a similar manner for colors where forward voltage groups are measured and binned, single forward voltage groups will be shipped

on any packing unit. E. g. GW CSSRM2.CM-M1M3-XX58-1 means that only one forward voltage group K2,L1,L2,M1,M2 will be

shippable.

1) page 24

1) Seite 24

GW CSSRM2.CM-M5M7-A333-1

5000

220 ... 250

Q65112A1652

GW CSSRM2.CM-M5M7-XX53-1

5000

220 ... 250

Q65112A1650

GW CSSRM2.CM-M6M8-A333-1

5000

230 ... 260

Q65112A1651

GW CSSRM2.CM-M6M8-XX53-1

5000

230 ... 260

Q65112A1649
