2017-10-26

1

2017-10-26

OSLON Square

Datasheet

Version 1.5

GW CSSRM2.PM

Third generation of OSLON Square with improved

radiation pattern and enhanced performance. Most

compact high-power LED with well known superior

robustness, high reliability, long lifetime and low

thermal resistance.

Die dritte Generation OSLON Square mit verbesserter

Abstrahlcharakteristik und nochmals verbesserter

Leistung. Die kompakte High-Power LEDs bietet

erprobte Zuverlässigkeit und lange Lebensdauer bei

niedrigstem Wärmewiderstand.

Features:

Besondere Merkmale:

•

Package: SMT ceramic package with silicone resin

and silicone lens

•

Gehäusetyp: SMT-Keramikgehäuse mit

Silikonverguss und -linse

•

Viewing angle at 50 % I

V: 120°

•

Abstrahlwinkel bei 50 % I

V: 120°

•

Color: 3000 K - 6500 K (white)

•

Farbe: 3000 K - 6500 K (weiß)

•

CRI: min. 70 ( typ. 72 )

•

CRI: min. 70 ( typ. 72 )

•

Luminous Flux: typ. 314 lm @ 5000 K, 85 °C

•

Lichtstrom: typ. 314 lm @ 5000 K, 85 °C

•

Luminous efficacy: typ. 160 lm/W @ 5000 K,

85 °C

•

Lichtausbeute: typ. 160 lm/W @ 5000 K, 85 °C

•

Corrosion Robustness: Superior Corrosion

Robustness

•

Korrosionsstabilität: Höchste

Korrosionsbeständigkeit

•

Lumen Maintenance: Test results according to

IESNA LM-80 available

•

Lichtstromerhaltung: Testergebnisse nach

IESNA LM-80 verfügbar

Applications

Anwendungen

•

Industrial lighting

•

Industriebeleuchtung

•

Outdoor lighting

•

Außenbeleuchtung

•

Street and tunnel lighting

•

Straßen und Tunnel
