Bro adc om

Altima Communications, Inc.

A Broadcom Company

P.O. Box 57013

16215 Alton Parkway

Irvine, CA 92619-7013

Printed in the U.S.A.

REVISION HISTORY

Broadcom® and the pulse logo® are registered trademarks of Broadcom Corporation and/or its subsidiaries in the United

States and certain other countries. All other trademarks are the property of their respective owners.

This data sheet (including, without limitation, the Broadcom component(s) identified herein) is not designed, intended, or

certified for use in any military, nuclear, medical, mass transportation, aviation, navigations, pollution control, hazardous

substances management, or other high risk application. BROADCOM PROVIDES THIS DATA SHEET "AS-IS", WITHOUT

WARRANTY OF ANY KIND. BROADCOM DISCLAIMS ALL WARRANTIES, EXPRESSED AND IMPLIED, INCLUDING,

WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR

PURPOSE, AND NON-INFRINGEMENT.

Revision

Date

Change Description

AC207-DS04-405-R

07/08/02

Minor text updates.

AC207-DS03-R

06/07/02

Minor technical update.

AC207-DS02-R

06/20/01

Updated tables.

AC207-DS01-R

02/08/01

Updated text in ”Scrambler” subsection of ”Functional Description” to

read that “When the BT Control register 23.11 is set to 1 the data

scrambling function is disabled, the 5-bit data stream is clocked directly

to the device’s PMA sublayer.”

Added pin #114 to “DGND” of Table 12, ”Power and Ground,” on page

16.

Added pins # 1, 2, 3, 4, 6, 7, 8, 9, 11, 12, 13, 14, 16, 18, 19, 20, 21, 22,

24, 25, 26, 27 to Table 13, ”No Connects,” on page 16.

Updated Section 4 ”Electrical Characteristics” and Section 5 ”Digital

Timing Characteristics”.

Various text changes.

Added Section 6 ”Mechanical Information”, outlining packaging

specifications.

Updated Digital Input Voltage from “–0.5V to Vcc” to “–0.5V to 3.3V” in

Section 4 ”Electrical Characteristics”.

Updated LED Timing.

AC207-DS00-R

10/9/00

Initial release.
