Absolute Maximum Ratings(Note 1)

Power Supply Voltage (V

CC) ............................ 0V to +7.0V

Input Voltage (V

IN) .............................................. 0V to VCC

Output Current (I

OUT) ................................................. 30mA

Power Dissipation (P

D) ........................................... 250mW

Storage Temperature Range (T

S) ............ –55°C to +125°C

Operating Ratings(Notes 2, 3, 4)

Supply Voltage (V

IN) ................................... +3.0V to +3.6V

........................................................ or +4.5V to +5.5V

Ambient Temperature (T

A), Note 5 ............ –40°C to +85°C

Junction Temperature (T

J), Note 5 ............ –40°C to 100°C

Resistor to Dissipate Power (R

EXT) .................. 10Ω to 50Ω

Laser Diode Serial Resistor (R

SER) .................... 0Ω to 50Ω

Resistor to Adjust Current (R

SET), Note 6

......................................................... 700

Ω to 20,000Ω

Package Thermal Resistance

MSOP

(θ

JA) Still-Air ...................................................... 113°C/W

(ψ

JB) Still-Air ........................................................ 74°C/W

GND = 0V; V

CC = 3.3V ±10% or VCC = 5.0V ±10%; TA = –40°C to +85°C

Symbol

Parameter

Condition

Min

Typ

Max

Units

Input HIGH Voltage

CC–1.165

CC–0.880

IN, /DIN, /EN)

Input LOW Voltage

CC–1.810

CC–1.475

IN, /DIN, /EN)

REF

Reference Voltage

1.7

2.0

2.3

Input LOW Current

I = VIL(min)

0.5

µA

IN, /DIN, /EN)

Input HIGH Current

100

µA

IN, /DIN, /EN)

Supply Current

MOD = 25mA

OUT_OFF

Output LOW Current

450

1000

µA

(/EN = HIGH)

OUT

Modulation Current

RSET

OUT/IRSET

—

OUT

Voltage at OUT, /OUT

CC–1.4

OUT

Capacitance on OUT, /OUT

2.5

Note 1.

Specification for packaged product only.

DC ELECTRICAL CHARACTERISTICS(Note 1)

Note 1.

Permanent device damage may occur if ABSOLUTE MAXIMUM RATINGS are exceeded. This is a stress rating only and functional operation

is not implied at conditions other than those detailed in the operational sections of this data sheet. Exposure to ABSOLUTE MAXIMUM

RATlNG conditions for extended periods may affect device reliability.

Note 2.

The data sheet limits are not guaranteed if the device is operated beyond the operating ratings.

Note 3.

The device is guaranteed to meet the DC specifications, shown in the table above, after thermal equilibrium has been established. The device

is tested in a socket such that transverse airflow of

≥500lfpm is maintained.

Note 4.

The voltage drop across REXT and RSER plus Laser Diode must not be greater than 1.4V.

Note 5.

Commercial devices are guaranteed from 0

°C to +85°C ambient temperature.

Note 6.

RSET minimum 430Ω.
