AD8214
Data Sheet
Rev. A | Page 8 of 16
50
70
90
110
OVERDRIVE VOLTAGE (mV)
5
15
25
35
45
55
65
75
85
95
ROUT = 3.3kΩ
ROUT = 5kΩ
Figure 16. Rise Time vs. Overdrive Voltage
(+IN > –IN by Specified VOD)
100ns/DIV
VOD = 15mV
VOD = 5mV
OUT
2V/DIV
–IN
10mV/DIV
+IN
Figure 17. Typical Propagation Delay (ROUT = 5 kΩ)
100ns/DIV
VOD = 20mV
OUT
2V/DIV
–IN
10mV/DIV
+IN
VOD = 10mV
Figure 18. Typical Propagation Delay (ROUT = 5 kΩ)
100ns/DIV
VOD = 50mV
VOD = 30mV
OUT
2V/DIV
–IN
30mV/DIV
+IN
Figure 19. Typical Propagation Delay (ROUT = 5 kΩ)
100ns/DIV
VOD = 100mV
VOD = 100mV
OUT
2V/DIV
–IN 50mV/DIV
+IN
Figure 20. Typical Propagation Delay (ROUT = 5 kΩ)
50
70
90
110
130
150
170
190
OVERDRIVE VOLTAGE (mV)
15
25
35
45
55
65
75
85
95
ROUT = 3.3kΩ
ROUT = 5kΩ
Figure 21. Propagation Delay vs. Overdrive Voltage
(–IN > +IN by Specified VOD, Output High to Low)
