Data Sheet

AD8363

Rev. B | Page 13 of 29

600

400

200

800

1.34

1.36

1.38

1.40

1.42

1.44

1.46

VTEMP (V)

REPRESENTS

APPROXIMATELY

3000 PARTS FROM

SIX LOTS

Figure 27. Distribution of VTEMP Voltage at 25oC, No RF Input

100

0.1

4.0

4.1

4.2

4.3

4.4

4.5

4.6

4.7

4.8

4.9

5.0

VTCM2 (V)

VTCM2 INCREASING

VTCM2 DECREASING

Figure 28. Supply Current vs. VTCM2

2.34

2.33

2.32

2.31

2.30

2.29

2.28

2.27

2.26

–30

–25

–20

–15

–10

–5

PIN (dBm)

Figure 29. Change in VREF with Input Amplitude for Eleven Devices

600

500

400

300

200

100

2.24

2.26

2.28

2.30

2.32

2.34

2.36

VREF (V)

REPRESENTS

APPROXIMATELY

3000 PARTS FROM

SIX LOTS

Figure 30. Distribution of VREF, 25°C, No RF Input

2.320

2.318

2.316

2.314

2.312

2.310

2.308

2.306

2.304

2.302

2.300

4.5

4.6

4.7

4.8

4.9

5.0

5.1

5.2

5.3

5.4

5.5

VPOS (V)

Figure 31. Change in VREF with VPOS for Nine Devices

2.325

2.320

2.315

2.310

2.305

2.300

2.290

2.295

–40

–20

100

120

TEMPERATURE (°C)

Figure 32. Change in VREF with Temperature for Eleven Devices
