2 / 5 page

SIM-AMS 1-R Order No.: 2271031

http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=2271031

PHOENIX CONTACT Inc., USA

Page 2 / 5

http://www.phoenixcon.com

Mar 15, 2010

Number of contacts, type

Pin dimensions

1,1 x 0,5 mm

Hole diameter

1.4 mm

Color

green

Insulating material

Standards/regulations

DIN VDE 0110b, Gr. C for 250 V DC

Certificates / Approvals

Certification

CSA, GOST, UL

CSA

Nominal voltage UN

300 V

Nominal current IN

5 A

Nominal voltage UN

300 V

Nominal current IN

5 A

Accessories

Item

Designation

Description

Marking

1051993

B-STIFT

Marker pen, for manual labeling of unprinted Zack strips, smear-

proof and waterproof, line thickness 0.5 mm

1401404

BN WH

Marker pin, unprinted: for individual labeling with M-PEN, lettering

field size: 4 x 4 mm

2701404

BN-TRK

Marker pin, lettering area 7.5 x 4 mm, unprinted for individual

labeling with M-PEN

0810902

BNB

WH:GROSSBUCHSTABEN

Marker pins, printed with up to 3 digits, 100 identically printed

marker pins per package, printed with: Upper case letters A-Z

0810928

BNB WH:SO

Marker pins, printed with up to 3 digits, 100 identically printed

marker pins per package, printed according to customer

requirements

0810915

BNB WH:SYMBOLE

Marker pins, printed with up to 3 digits, 100 identically

printed marker pins per package, printed with: symbols

(+,-,/,~,ERD,SERD, L1, L2, L3 PE, PEN)
