https://www.phoenixcontact.com/pi/products/2834643

07/23/2018 Page 2 / 5

Relay Module - PR2-RSC3-LDP-24DC/2X21 - 2834643

Technical data

Coil side

Nominal input voltage UN

24 V DC

Input voltage range in reference to UN

see diagram

Typical input current at UN

38 mA

Typical response time

13 ms

Typical release time

14 ms

Protective circuit

Damping diode

Operating voltage display

Green LED

Power dissipation for nominal condition

0.91 W

Contact side

Contact type

2 PDT

Type of switch contact

Single contact

Contact material

Maximum switching voltage

250 V AC/DC

Minimum switching voltage

5 V

Min. switching current

1 mA

Maximum inrush current

20 A (15 ms)

Limiting continuous current

10 A

Interrupting rating (ohmic load) max.

2500 VA (for 250 V AC)

240 W (at 24 V DC)

144 W (at 48 V DC)

108 W (at 60 V DC)

72 W (at 110 V DC)

110 W (at 220 V DC)

General

Test voltage relay winding/relay contact

2 kV (50 Hz, 1 min.)

Test voltage relay contact/relay contact

2 kV (50 Hz, 1 min.)

Operating mode

100% operating factor

Degree of protection

RT I (Relay)

Mechanical service life

5x 107 cycles

Mounting position

any

Assembly instructions

In rows with zero spacing

Connection data input side

Connection name

Coil side

Connection method

Screw connection

Stripping length

7 mm

Screw thread

Conductor cross section solid

0.14 mm² ... 2.5 mm²

Conductor cross section flexible

0.14 mm² ... 2.5 mm²

Conductor cross section AWG

26 ... 14
