AD8338

Data Sheet

Rev. B | Page 4 of 19

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

VBAT to COMM

−0.3 V to +5.5 V

INPR, INPD, INMD, INMR, MODE, GAIN,

FBKM, FBKP, OUTM, OUTP, VAGC,

VREF, OFSN

COMM to VBAT

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Maximum Junction Temperature

150°C

Lead Temperature (Soldering, 10 sec)

300°C

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

Table 3. Thermal Resistance

Package Type

Unit

16-Lead LFCSP

48.75

°C/W

ESD CAUTION
