ADL5330

Data Sheet

Rev. B | Page 10 of 24

OP1dB (dBm)

18.5 19 19.5

20.5

21 21.5 22 22.5

24.5

23.5

Figure 21. OP1dB Distribution at 900 MHz at Maximum Gain, VGAIN = 1.4 V

OP1dB (dBm)

9.5 10 10.5

11.5

12 12.5 13 13.5

15 15.5

14.5

Figure 22. OP1dB Distribution at 2200 MHz at Maximum Gain, VGAIN = 1.4 V

OIP3 (dBm)

28.5

29.5

30.5

31.5

33.5

34.5

32.5

Figure 23. OIP3 Distribution at 900 MHz at Maximum Gain, VGAIN = 1.4 V

OIP3 (dBm)

18.5

19 19.5 20 20.5

22.5

23.5

21.5

Figure 24. OIP3 Distribution at 2200 MHz at Maximum Gain; VGAIN = 1.4 V

FREQUENCY (MHz)

10,000

100

1,000

–10

–20

–30

–40

–50

VGAIN = 0.2V

VGAIN = 0.4V

VGAIN = 0.6V

VGAIN = 0.8V

VGAIN = 1.0V

VGAIN = 1.2V

VGAIN = 1.4V

Figure 25. Gain vs. Frequency (Differential)

FREQUENCY (MHz)

10,000

1,000

100

–10

–20

–30

–40

–50

VGAIN = 0.2V

VGAIN = 0.4V

VGAIN = 0.6V

VGAIN = 0.8V

VGAIN = 1.0V

VGAIN = 1.2V

VGAIN = 1.4V

Figure 26. Gain vs. Frequency (Using ETC1-1-13 Baluns)
