6 / 39 page

ADRF6518

Data Sheet

Rev. A | Page 6 of 39

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Supply Voltages, VPS, VPSD

3.45 V

VPI

5.25 V

ENBL, LE, CLK, DATA, SDO

VPSD + 0.5 V

INP1, INM1, INP2, INM2, VICM

VPS + 0.5 V

OPP1, OPM1, OPP2, OPM2, VOCM

VPS + 0.5 V

OFS1, OFS2, VPK, RAVG

VPS + 0.5 V

VGN1, VGN2, VGN3

VPS + 0.5 V

Internal Power Dissipation

1.25 W

θJA (Exposed Pad Soldered to Board)

37.4°C/W

Maximum Junction Temperature

150°C

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Lead Temperature (Soldering 60 sec)

300°C

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

ESD CAUTION
