UNISONIC TECHNOLOGIES CO., LTD

LR1102

CMOS IC

www.unisonic.com.tw

1 of 12

QW-R502-038. K

LOW NOISE 150mA LDO

REGULATOR



DESCRIPTION

The UTC LR1102 families are CMOS-based voltage

regulator ICs with extremely low supply current, high output

voltage accuracy, high Ripple Rejection and chip enable circuit.

These ICs performance are excellent and with SOT-25

package, thus these ICs are very suitable for hand-held

communication equipment.



FEATURES

* Ultra-Low Supply Current : Typ. 35µA

* Standby Mode: Typ. 0.1µA

* Low Dropout Voltage: Typ. 0.2V (IOUT = 100mA)

* Excellent Line Regulation: Typ. 0.05%/V

* High Ripple Rejection: Typ. 70dB (f = 1kHz)



ORDERING INFORMATION

Ordering Number

Pin Assignment

Halogen Free

Package

1

2

3

4

5

Packing

LR1102XG-xx-AF5-R

SOT-25

I

G

C

N

O

Tape Reel

Note: Pin Assignment: I: VDD O: VOUT G: GND C: CE/ CE

N: No Connection
