07/23/2018   Page 2 / 5

Relay Module - PLC-RSC-230UC/21-21/EX - 2909512

Technical data

Coil side

Typical response time

7 ms

Typical release time

10 ms

Protective circuit

Bridge rectifier Bridge rectifier

Operating voltage display

Yellow LED

Power dissipation for nominal condition

1.04 W

Contact side

Contact type

2 PDT

Type of switch contact

Single contact

Contact material

AgNi

Maximum switching voltage

250 V AC/DC (The separating plate PLC-ATP should be installed for

voltages larger than 250 V (L1, L2, L3) between identical terminal blocks

in adjacent modules. Potential bridging is then carried out with FBST 8-

PLC... or ...FBST 500...)

Minimum switching voltage

5 V AC/DC (at 10 mA)

Min. switching current

10 mA (At 5 V)

Maximum inrush current

15 A (300 ms)

Limiting continuous current

6 A

Interrupting rating (ohmic load) max.

140 W (at 24 V DC)

85 W (at 48 V DC)

60 W (at 60 V DC)

44 W (at 110 V DC)

60 W (at 220 V DC)

1500 VA (for 250 V AC)

Switching capacity in acc. with DIN VDE 0660/IEC 60947

2 A (at 24 V, DC13)

0.2 A (at 250 V, DC13)

3 A (at 24 V, AC15)

3 A (at 120 V, AC15)

3 A (at 250 V, AC15)

General

Test voltage relay winding/relay contact

4 kV AC (50 Hz, 1 min.)

Test voltage PDT/PDT

2.5 kV AC (50 Hz, 1 min.)

Operating mode

100% operating factor

Degree of protection

RT III (Relay)

IP20 (Relay base)

Mechanical service life

ATEX

 II 3G Ex ec nC IIC T4 Gc

EU-type examination certificate

IBExU16ATEXB015 X

IECEx

Ex ec nC IIC T4 Gc

IECEx certificate

IECEx IBE 16.0029X

UL, USA

Class I, Zone 2, AEx nA nC IIC T6

UL, USA/Canada

Class I, Div. 2, Groups A, B, C, D
