background image
ADL5202
Data Sheet
Rev. D | Page 28 of 29
Configuration Options for the USB Section
Table 10. Bill of Materials for USB Section
Components
Default Conditions
C7, C8
22 pF (Size 0603)
C13
1000 pF (Size 0603)
C2, C3, C4, C6, C10, C11, C12, C14, C16, C46
0.1 µF (Size 0402)
C9, C15
1 µF (Size 0402)
C1, C5
10 pF (Size 0402)
CR1
Green LED ( Panasonic LNJ308G8TRA)
P3
USB SMT connector (Hirose Electric UX60A-MB-5ST 240-0003-4)
R1, R2, R5
2 kΩ (Size 0603)
R6,
78.7 kΩ (Size 0603)
R7
140 kΩ (Size 0603)
R3, R4
100 kΩ (Size 0603)
R83
0 Ω (Size 0603)
U2
USB microcontroller (Cypress CY7C68013A-56LFXC)
U1
64 kB EEPROM (Microchip 24LC64-I/SN)
U3
Low dropout regulator (Analog Devices ADP3334ACPZ)
Y1
24 MHz crystal oscillator (AEL Crystals X24M000000S244)
