Relay Module - PLC-RSC- 36DC/21AU - 2966980

Technical data

Contact side

Type of switch contact

Single contact

Contact material

AgSnO, hard gold-plated

Maximum switching voltage

30 V AC

36 V DC

Minimum switching voltage

100 mV (at 10 mA)

Min. switching current

at 24 V

Contact side (with destroyed gold layer)

Note

the following values are applicable if a gold layer is destroyed

Maximum switching voltage

250 V AC/DC

Minimum switching voltage

5 V (at 100 mA)

Limiting continuous current

6 A

Min. switching current

10 mA (at 12 V)

Interrupting rating (ohmic load) max.

140 W (at 24 V DC)

20 W (at 48 V DC)

18 W (at 60 V DC)

23 W (at 110 V DC)

40 W (at 220 V DC)

1500 VA (for 250 V AC)

Connection data input side

Connection name

Coil side

Connection method

Screw connection

Stripping length

8 mm

Screw thread

M3

Conductor cross section solid

0.14 mm² ... 2.5 mm²

Conductor cross section flexible

0.14 mm² ... 2.5 mm²

0.2 mm² ... 2.5 mm² ()

2x 0.5 mm² ... 1.5 mm² ()

Conductor cross section AWG

26 ... 14

Connection data output side

Connection name

Contact side

Connection method

Screw connection

Stripping length

8 mm

Screw thread

M3

Conductor cross section solid

0.14 mm² ... 2.5 mm²

Conductor cross section flexible

0.14 mm² ... 2.5 mm²

0.2 mm² ... 2.5 mm² ()

2x 0.5 mm² ... 1.5 mm² ()

Conductor cross section AWG

26 ... 14
