background image

PHOENIX CONTACT Inc., USA

Page 1 / 6

http://www.phoenixcon.com

Aug 19, 2011

Extract from the online

catalog

PLC-RSC-125DC/21

Order No.: 2980021

http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=2980021

PLC relay, consisting of basic terminal block PLC-BSC.../21 with screw

connection and pluggable miniature relay with power contact, for

assembly on DIN rail NS 35/7.5, 1 PDT, input voltage 125 V DC

Commercial data

GTIN (EAN)

4

017918

608446

sales group

G220

Pack

10 pcs.

Customs tariff

85364900

Product notes

WEEE/RoHS-compliant since:

01/23/2006

http://

www.download.phoenixcontact.com

Please note that the data given

here has been taken from the

online catalog. For comprehensive

information and data, please refer

to the user documentation. The

General Terms and Conditions of

Use apply to Internet downloads.

Technical data

Coil side

Nominal input voltage UN

125 V DC

Contact side

Contact type

Single contact, 1-PDT
