ELECTRO－OPTICAL CHARACTERISTICS
ABSOLUTE MAXIMUM RATINGS AT Ta=25℃
PARAMETER
MAXIMUM RATING
UNIT
Supply Voltage (VDD)
6.0
V
Output Voltage (VO)
VDD ＋0.3
V
Operating Temperature Range
-20℃ to + 70℃
Storage Temperature Range
-30℃ to + 80℃
Lead Soldering Temperature
[1.6mm(.063") From Body]
260℃ for 5 Seconds
ELECTRICAL OPTICAL CHARACTERISTICS AT Ta=25℃
PARAMETER
SYMBOL MIN.
TYP.
MAX.
UNIT
TEST
CONDITION
Data Rate
Ts
0.1
－
16
Mbps
NRZ signal
Operating Voltage
VDD
4.75
－
5.25
V
Peak Sensitivity Wavelength
λPeak
－
650
－
nm
Input Sensitivity
Pi
-24
－
-14
dBm
Dissipation current
IDD
2
7
10
mA
NRZ signal
High level output voltage
VOH
2.4
4.8
－
V
Dc Light ,
IOH = -20 µA
Low level output voltage
VOL
－
0.2
0.4
V
Dark ,
IOL = 0.6mA
“Low High”propagation delay time
tPLH
－
－
166
ns
“High Low”propagation delay time
tPHL
－
－
166
ns
Pulse width distortion
Δ
tW
-18
－
+18
ns
*1
Jitter
Δ
tj
－
1
5
ns
*1
Rise Time
tr
－
8
20
ns
*1
Fall Time
tf
－
8
20
ns
*1
Part No. : LTDL-RX16P01B DATA SHEET
Page :
2
of
4
BNS-OD-C131/A4
