L1803

Preliminary

LINEAR INTEGRATED CIRCUIT

UNISONICTECHNOLOGIESCO.,LTD

6 of 6

www.unisonic.com.tw

QW-R102-058.d



TYPICAL APPLICATION CIRCUIT

IN

EN

VCC

PG

OUT

SS

FB

GND

R3

C1

C3

R1

C2

R2

UTC

L1803

Table 1. Capacitor Values for Programming the Soft-Start Time (Note)

CSS

SOFT-START TIME

Open

0.1ms

270pF

0.5ms

560pF

1ms

2.7nF

5ms

5.6nF

10ms
