13.7

21.1

33

Mounting bracket

attachment side

GT1 Series

19

17.75

14.5

Tin plating

8

5

5

2.8

1.5

16.8

Part Number

CL No.

Remarks

1.5mm

With ground terminal

GT1-1 / 1PP-HU(10)

751-0025-1-10

1.5mm

Without ground terminal

GT1-1 / 1PP-HU(11)

751-0025-1-11

1.0mm

With ground terminal

Note: Used with separate retainer (GT1-1/1PP-R).

Note: Mount this item after provisional insertion into the housing, or after terminal insertion.

Item

Material

Finish

Housing

PBT

Light gray

Ground terminal Phosphor bronze

Tin plating

Part Number

CL Number

Material

Color

GT1-1/1PP-R

751-0027-7

PBT

Dark gray

M Connectors

Housings

Mounting bracket

attachment side

Retainer (exclusively for GT1-1/1PP-HU)

The product information in this catalog is for reference only. Please request the Engineering Drawing for the most current and accurate design information.

All non-RoHS products have been discontinued, or will be discontinued soon. Please check the products status on the Hirose website RoHS search at www.hirose-connectors.com, or contact your Hirose sales representative.
