AD9577

Data Sheet

Rev. A | Page 16 of 44

ABSOLUTE MAXIMUM RATINGS

Table 13.

Parameter

Rating

VS to GND

−0.3 V to +3.6 V

REFCLK to GND

−0.3 V to VS + 0.3 V

LDO to GND

−0.3V to VS + 0.3 V

XT1, XT2 to GND

−0.3 V to VS + 0.3 V

SSCG, MAX_BW, MARGIN, SCL, SDA,

REFSEL to GND

−0.3 V to VS + 0.3 V

REFOUT, OUTxP, OUTxN to GND

−0.3 V to VS + 0.3 V

Junction Temperature1

150°C

Storage Temperature

−65°C to+150°C

Lead Temperature (10 sec)

300°C

1 See the Thermal Characteristics section for θJA.

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL CHARACTERISTICS

Thermal impedance measurements were taken on a 4-layer

board in still air in accordance with EIA/JESD51-7.

Table 14. Thermal Resistance

Package Type

θJA

Unit

40-Lead LFCSP

27.5

°C/W

ESD CAUTION
