Electrical Characteristics

Inductance

[Within]

(μH) ※1

Temperature

Rise Current

(A) ※3

Saturation Current

at 20℃(A) ※2

D.C.R. at 20℃

[Within] (mΩ)

Part Number

7.40

CD40D26MBNP-R20NC

0.20 ± 30%

9.20 ± 30%

14.40

5.80

CD40D26MBNP-R33NC

0.33 ± 30%

12.00 ± 30%

11.60

5.20

CD40D26MBNP-R56NC

0.56 ± 30%

15.00 ± 30%

9.40

5.00

CD40D26MBNP-R80NC

0.80 ± 30%

18.00 ± 30%

8.70

4.40

CD40D26MBNP-1R0NC

1.00 ± 30%

21.00 ± 30%

7.20

4.30

CD40D26MBNP-1R5MC

1.50 ± 20%

24.00 ± 30%

6.30

3.80

CD40D26MBNP-2R2MC

2.20 ± 20%

30.00 ± 30%

5.30

2.80

CD40D26MBNP-3R3MC

3.30 ± 20%

46.00 ± 30%

4.30

2.60

CD40D26MBNP-4R7MC

4.70 ± 20%

59.00 ± 30%

3.50

2.20

CD40D26MBNP-6R8MC

6.80 ± 20%

80.00 ± 30%

2.90

1.90

CD40D26MBNP-100MC

10.00 ± 20%

117 ± 30%

2.50

1.30

CD40D26MBNP-150MC

15.00 ± 20%

198 ± 30%

1.90

1.20

CD40D26MBNP-220MC

22.00 ± 20%

261 ± 30%

1.70

0.95

CD40D26MBNP-330MC

33.00 ± 20%

391 ± 30%

1.40

※1 Measuring frequency inductance at 100kHz,1V.

※2 Saturation current: This indicates the actual value of D.C. current when the inductance becomes 30% lower than its initial

value.

※3 Temperature rise current: The actual value of D.C. current when temperature of coil increased △T=40℃(Ta＝20℃).

(The part is mounted on PCB to test.)

CD40D26MB

SMD Power Inductor

Solder Reflow Condition

Note： This specification is subject to change without notice. Please contact your nearest sales office for updated information when placing an order.

Page 2 of 4

Ver. 2018-05-02
