1-Watt SMD 6x6mm Dome Lens

OVSPxBCR44 Series

Luminous Intensity

Bin

Min (mcd)

Max (mcd)

AJ

45,000

56,000

AK

56,000

71,500

Rank

YU

YL

Cx

0.274 0.283 0.307 0.303 0.283 0.290 0.310

0.307

Cy

0.301 0.284 0.316 0.333 0.284 0.270 0.299

0.316

Rank

XU

XL

Cx

0.303 0.307 0.317 0.315 0.307 0.310 0.319

0.317

Cy

0.333 0.316 0.325 0.343 0.316 0.299 0.310

0.325

Rank

WU

WL

Cx

0.315 0.317 0.329 0.329 0.317 0.319 0.329

0.329

Cy

0.343 0.325 0.336 0.354 0.325 0.310 0.319

0.336

Rank

VU

VL

Cx

0.329 0.329 0.345 0.347 0.329 0.329 0.343

0.345

Cy

0.354 0.336 0.350 0.368 0.336 0.319 0.331

0.350

Chromaticity Coordinates (x, y)

Standard Bins

code and a single CCT code. Orders are filled utilizing all of the intensity codes and CCT codes listed in the follow-

ing tables. Optek will not accept orders for single intensity codes or single CCT codes.
