L16B45B

Advance

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

4 of 10

www.unisonic.com.tw

QW-R102-085.b



ABSOLUTE MAXIMUM RATING

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

VDD

0~7.0

Input Voltage

VIN

-0.4 ~ VDD+0.4

Output Current

IOUT

Output Voltage

VOUT

-0.5 ~ +11

Clock Frequency

FCLK

MHz

GND Terminal Current

IGND

720

Power Dissipation (TA=25°C)

0.9

Storage Temperature

TSTG

-55 ~ +150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



DC ELECTRICAL CHARACTERISTICS (VDD=5.0V, TA=25°C)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

“H” Level

VIH

0.7×VDD

VDD

Input Voltage

“L” Level

VIL

GND

0.3×VDD

Output Leakage Current

IOH

VOH=9V

0.2

VOL

IOL=1.0mA

0.4

Output Voltage (S-OUT)

VOH

IOH=-1.0mA

4.6

IOL1

VOUT=1V, REXT=910Ω

±2

Output Current (Bit to Bit)

IOL2

VOUT=1V, REXT=420Ω

±2

IOL3

VOUT=1V, REXT=910Ω

±4

Output Current (chip to chip)

IOL4

VOUT=1V, REXT=420Ω

±4

Output Current vs. Supply

Voltage Regulation

%/VDD

REXT=420Ω, TA=-40~85°C

±1

%/V

Output Current vs. Output

Voltage Regulation

%/VDS

REXT=420Ω, TA=-40~85°C

±0.1

%/V

Pull-Up Resistor

RIN (up)

500

KΩ

Pull-Down Resistor

RIN (down)

500

KΩ

IDD (off) 1

REXT=OPEN, OUT0~15=off

“OFF”

IDD (off) 2

REXT=420Ω, OUT0~15=off

Supply Current

“ON”

IDD (on) 1

REXT=420Ω, OUT0~15=on
