UD8973
Preliminary
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
3 of 6
www.unisonic.com.tw
QW-R140-006.a
ABSOLUTE MAXIMUM RATING
PARAMETER
SYMBOL
RATINGS
UNIT
Supply Voltage
VDD
0~6.5
V
Gate Voltage
VG
VDD
V
Power Dissipation
PD
0.7
W
Storage Temperature Range
TSTG
-55 ~ +150
°C
Operating Temperature Range
TOPR
-40 ~ +85
°C
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
THERMAL INFORMATION
PARAMETER
SYMBOL
RATINGS
UNIT
Junction to Ambient
θJA
178
°C/W
ELECTRICAL CHARACTERISTICS (TJ=25°C, unless otherwise specified)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
Supply Current
IDD
VDD=5V
220
uA
VDD=5V, IO=1A
100
mΩ
Switch On-Resistance
RDS
VDD=3.8V, IO=1A
110
mΩ
Output Current
IO
VDD=5V
3.0
A
Short-Circuit Current
S
I
TEST CIRCUIT 1
50
mA
