L8221

LINEAR INTEGRATED CIRCUIT

UNISONIC TECHNOLOGIES CO., LTD

4 of 5

www.unisonic.com.tw

QW-R123-020.B



ELECT RI CAL CH ARACT ERI ST I CS (Cont .)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Drain Characteristics

D1 Output

Voltage High

VD1

I D1=10mA, VIN=15.5V

1.8

2.0

2.2

Leakage Current

ILEAK1

V D1=0.5, VIN=14V

D2 Output

Voltage High

VD2

ID2=10mA, VIN=14V

1.8

2.0

2.2

Leakage Current

ILEAK2

VD2=0.5, VIN=15.5V

D1, 2

Delta VD vs. VCC

∆VDV

VCC=9 ~ 21V

0.5

%/V

Delta VD vs. TJ

∆VDT

TJ=-40 ~ +85°C

ppm

FET Current Range

I D1, I D2

Drain Current

ID1, ID2, RCALA=22K

Delta Id vs. VCC

∆IDV

VCC=9 ~ 21V

0.5

%/V

Delta Id vs. TJ

∆IDT

TJ=-40 ~ +85°C

0.05

%/°C

Notes: 1. The total combined load currents should not exceed the stated maximum load current.

2. The UTC L8221 series will also reject DiSEqC and other common switching tone bursts.
