background image
B36
■Straight Jack
CL No.
Part Number
339-0009-9
MMCX-J-FHSB
CL No.
Part Number
339-0011-0
MMCX-J-178B/U
CL No.
Part Number
339-0016-4
MMCX-PBJ-066
CL No.
Part Number
339-0022-7
MMCX-J-088
● Ø1.37 Single Shield Cable
7.8
14.8
● Ø1.32 Double Shield Cable
● Ø1.13 Single Shield Cable
8.6
5.1
0.8
6.5HEX
No.10-32UNF-2A
10
5.1
+0.1
0
Panel thickness : 1.3 to 2.5mm
Recomonded panel cut-out
●Ø1.48 Single Shielded Cable
7.8
14.8
●RG-178B/U and equivalent
7.8
14.8
