TDA7052A
LINEAR INTEGRATED CIRCUIT
UNISONIC TECHNOLOGIES CO., LTD
4 of 5
www.unisonic.com.tw
QW-R107-075.B
T Y PI CAL APPLI CAT I ON CI RCU I T
I + i
I - i
+
+
-
Vref
STABILIZER
Thermal Protection/MCL
4
2
7
1
5
8
6
3
n.c.
+
-
Note 1
100nF
220
μF
+
VP=6V
RL=8Ω
Ground
DC
Volume
Control
5k
Ω
RS
Signal Input
0.47
μF
Note 1. This capacitor can be omitted if the 220
μF electrolytic capacitor is connected close to pin 1.
4
1M
Ω
1
μF
+
Volume
Control
Application with potentiometer as volume control; maximum gain=30dB
+
Inverted Output
Non-inverted
Output
Power
Ground
Signal
Ground
VP
