KEMET Part Number: SSHB21HS-R05910

KEMET, SSHB21HS, AC Line Filters, Dual Mode, 0.091 H

Dimensions

L

26mm MAX

T

23mm MAX

H

15.5mm MAX

LL

3.5mm +/-0.5mm

S

15mm +/-0.5mm

Packaging Specifications

Packaging: Tray

Packaging Quantity: 360

Weight: 14 g

General Information

Series: SSHB21HS

Style: Through-Hole

RoHS: Yes

Notes: Marking: R05 Lot No.

Miscellaneous: Temperature Rise Maximum: 55

K

Specifications

Voltage AC: 250 VAC

Inductance: 91 mH (10 kHz)

Current: 500 mA

Temperature Range: -25/+120C

DC Resistance: 1.88 Ohms
