AXC-051

PRELIMINARY

September 98

Page 3 of 4

98004-05-004-06.doc

IXYS Corporation 3540 Bassett Street, Santa Clara, CA 95054 TEL:408-982-0700 FAX:408-496-0670

IXYS Semiconductor, GmbH. Edisonstr. 15 D-68623 Lampertheim, Germany TEL:+49-6206-503-0 FAX:+49-6206-503-627

Thermal Resistance

Fig5. - Load Transient Response

Parameter

Typ

Max

Units

Junction-to-Case [

JC

]

1.0

°C/W

Case-to-Sink [

CS

]

0.50

°C/W

Junction-to-Ambient [

JA

62

°C/W

General Specifications

Parameter

Units

Weight

9.0

±0.5

gr.

Fig6. - Mechanical Drawing

a

b

c

d

R=e

g

f

h

n

w

s

m

k

mm

inch

min

max

min

max

a

4.90

5.90

0.193 0.232

b

2.62

2.87

0.103 0.113

c 10.29 10.54 0.405 0.415

d

1.22

1.32

0.048 0.052

e

1.40

1.50

0.055 0.059

f

0.97

1.01

0.038 0.040

g

4.40

5.40

0.173 0.213

h 13.80 14.20 0.543 0.559

k

3.54

3.78

0.139 0.149

m 5.20

6.20

0.205 0.244

n 21.00 22.60 0.827 0.890

s

2.39

2.69

0.094 0.106

w 18.10 18.60 0.713 0.732

a

b

c

d

R=e

g

f

h

n

w

s

m

k

mm

inch

min

max

min

max

a

4.90

5.90

0.193 0.232

b

2.62

2.87

0.103 0.113

c 10.29 10.54 0.405 0.415

d

1.22

1.32

0.048 0.052

e

1.40

1.50

0.055 0.059

f

0.97

1.01

0.038 0.040

g

5.50

6.40

0.217 0.252

h 13.80 14.20 0.543 0.559

k

3.54

3.78

0.139 0.149

m 19.25 20.16 0.758 0.794

n 21.00 22.60 0.827 0.890

s

2.39

2.69

0.094 0.106

w 18.10 18.60 0.713 0.732
