Device Selection Guide

Absolute Maximum Ratings at Ta=25°C

Model Number

Chip

Description

Material

Emitting Color

Common Cathode x=C

/

Common Anode x=A

PDM58460x-G05

InGaN

True Green

PDM58460x-G17

AlInGaP

Yellow Green

PDM58460x-Y04

Yellow

PDM58460x-A11

Amber

PDM58460x-R02

Orange-Red

PDM58460x-R11

Red

PDM58460x-R21

Deep Red

Parameter

Symbol

Rating

Unit

G17/Y04/A11/R02/R11/R21

G05

Power Dissipation per Dice

70

114

mW

Derating Liner from 25°C per Dice

--

0.33

0.4

mA/°C

Continuous Forward Current Per Dice

25

30

mA

Peak Current Per Dice (duty cycle

1/10, 1KHz)

90

100

mA

Reverse Voltage Per Dice

VR

5

5

V

Electrostatic Discharge (HBM)

ESD

/

1000

V

Operating Temperature

Topr

-35~+85

°C

Storage Temperature

Tstg

-35~+85

°C

Solder Conditions: 1/16 inch below seating plane for 3 -5 seconds at 260°C.
