ULN2012
Preliminary
LINEAR INTEGRATED CIRCUIT
UNISONICTECHNOLOGIESCO.,LTD
5 of 6
www.unisonic.com.tw
QW-R113-020.a
TEST CIRCUIT
Components in the test circuits are used only to obtain and confirm the device characteristics. These components
and circuits are not guaranteed to prevent malfunction or failure from occurring in the application equipment.
VIN
OPEN
VCE
ICEX
µA
Figure 1
OPEN
hFE=IC/IB
IC
VCE
IB
V
Figure 2
IIN
OPEN
mA
OPEN
VIN
Figure 3
IIN
OPEN
VCE
IC
µA
µA
Figure 4
OPEN
IC
VCE
V
V
VIN
Figure 5
OPEN
IR
µA
Figure 6
OPEN
IF
V
VF
Figure 7
